Container Specification

Exterior Length Width Height 20'-0" 8'-0" 8'-6" 6.058 m 2.438 m 2.591 m Interior Length Width Height 19'-4 13/16" 7'-8 19/32" 7'-9 57/64" 5.898 m 2.352 m 2.385 m

Weight			Door Opening
MGW	TARE	NET	Width	Height
52,910 lb	5,140 lb	47,770 lb	7'-8 1/8"	7'-5 3/4"
67,200 lb	5,290 lb	61,910 lb	2.343 m	2.280 m
24,000 kg	2,330 kg	21,670 kg	CU.M	CU.FT
30,480 kg	2,400 kg	28,080 kg	33.1	1,169
Purpose
Captioned units(MGW 30,480 KG) can be coordinated from EMCU 3204073 and EISU 3568118. Used for all kinds of general cargo.

Exterior Length Width Height 40'-0" 8'-0" 8'-6" 12.192 m 2.438 m 2.591 m Interior Length Width Height 39'-5 45/64" 7'-8 19/32" 7'-9 57/64" 12.032 m 2.352 m 2.385 m

Weight			Door Opening
MGW	TARE	NET	Width	Height
67,200 lb	8,820 lb	58,380 lb	7'-8 1/8"	7'-5 3/4"
			2.343 m	2.280 m
30,480 kg	4,000 kg	26,480 kg	CU.M	CU.FT
			67.5	2,385
Purpose
Used for all kinds of general cargo.

Exterior Length Width Height 40'-0" 8'-0" 9'-6" 12.192 m 2.438 m 2.896 m Interior Length Width Height 39'-5 45/64" 7'-8 19/32" 8'-9 15/16" 12.032 m 2.352 m 2.69 m

Weight			Door Opening
MGW	TARE	NET	Width	Height
67,200 lb	9,260 lb	57,940 lb	7'-8 1/8"	8'-5 49/64"
			2.343 m	2.585 m
30,480 kg	4,200 kg	26,280 kg	CU.M	CU.FT
			76.2	2,690
Purpose
Used for all kinds of general cargo.

Exterior Length Width Height 45'-0" 8'-0" 9'-6" 13.716 m 2.438 m 2.896 m Interior Length Width Height 44'-5 7/10'' 7'-8 19/32'' 8'-10 17/64'' 13.556 m 2.352 m 2.698 m

Weight			Door Opening
MGW	TARE	NET	Width	Height
67,200 lb	10,580 lb	56,620 lb	7'-8 1/8"	8'-5 3/4"
			2.340 m	2.585 m
30,480 kg	4,800 kg	25,680 kg	CU.M	CU.FT
			86.1	3,040
Purpose
Used for all kinds of general cargo.

Exterior Length Width Height 20'-0" 8'-0" 8'-6" 6.058 m 2.438 m 2.591 m Interior Length Width Height 18'- 17/32" 7'-6 15/32" 7'-5 39/54" 5.5 m 2.298 m 2.276 m

Nominal			Weight
Cubic Capacity			MGW	TARE
1006 cu.ft.			67,180 lb	6,700 lb
			30,480 kg	3,040 kg
28.5 cu.m.			CU.M	CU.FT
			28.8	1,016
Cooling capacity	Air exchange rate		Type	Temp. control precision
w(kcal)/C(F)	CFM	cu.m/hr
11,000(9,460)/1.7(35) 6,280(5,400)/-18(0)	0-106	0-180	MHI CPE14-2BAIIIEU	+-0.25C
10,550(9,073)/2(35) 6,150(5,289)/-18(0)	0-142	0-240	CARRIER 69NT40-551-501	+-0.25C
Purpose
Used for all kinds of general cargo.

Exterior Length Width Height 40'-0" 8'-0" 9'-6" 12.192 m 2.438 m 2.896 m Interior Length Width Height 37'-11 55/64" 7'-6 15/32" 8'-4 5/32" 11.579 m 2.298 m 2.544 m

Nominal			Weight
Cubic Capacity			MGW	TARE
2,390 cu.ft.			74,960 lb	9,150 lb
			34,000 kg	4,150 kg
67.70 cu.m.			CU.M	CU.FT
			67.7	2,390
Cooling capacity	Air exchange rate		Type	Temp. control precision
w(kcal)/C(F)	CFM	cu.m/hr
11,000(9,460)/1.7(35) 6,280(5,400)/-18(0)	0-106	0-180	MHI CPE16-2BAIIIEV	+-0.25C
10,550(9,073)/2(35) 6,150(5,289)/-18(0)	0-142	0-240	CARRIER 69NT40-551-501	+-0.25C

Exterior Length Width Height 19'-10 1/2" 8'-0" 8'-6" 6.058 m 2.438 m 2.591 m Interior Length Width Height 19'-4 13/64" 7'-8 19/32" 7'-7 11/16" 5.898 m 2.352 m 2.329 m

Weight			Door Opening
MGW	TARE	NET	Width	Height
52,910 lb	5,310 lb	47,600 lb	7'-8 1/4"	7'-4 31/32"
24,000 kg	2,410 kg	21,590 kg	2.343 m	2.260 m
CU.M			CU.FT
32.5			1,148
Purpose
Captioned units can be coordinated from UGMU 490001~UGMU 490150 and EMCU 460161~EMCU 460520.

Exterior Length Width Height 20'-0" 8'-0" 8'-6" 6.058 m 2.438 m 2.591 m Interior Length Width Height 18'-5 31/32" 7'-3 23/32" 7'-3 59/64" 5.638 m 2.228 m 2.233 m Weight MGW TARE NET 74,950 lb 6,370 lb 68,580 lb 34,000 kg 2,890 kg 31,110 kg

Purpose

Captioned units can be coordinated from EISU 750000 to EISU 750300.

Exterior Length Width Height 40'-0" 8'-0" 8'-6" 12.192 m 2.438 m 2.591 m Interior Length Width Height 38'-7 39/64" 7'-3 23/32" 6'-4 61/64" 11.752 m 2.374 m 1.955 m Weight MGW TARE NET 99,210 lb 10,800 lb 89,410 lb 45,000 kg 4,900 kg 40,100 kg

CU.M	CU.FT
65.9	2,327
Purpose
Captioned units can be coordinated from EMCU 400362~EMCU 400601, UGMU 407001~UGMU 407050 and EISU 400001~EISU 400600.

Exterior Length Width Height 40'-0" 8'-0" 9'-6" 12.19 m 2.44 m 2.90 m Interior Length Width Height 39'-5 45/64" 7'-8 19/32" 8'-9 15/16" 12.03 m 2.35 m 2.69 m

Purpose

Captioned units can be coordinated from EISU 750000 to EISU 750300.
